All productsShowing 1–18 of 58 results
Monoblock directional control valves are essential components in hydraulic systems, providing the necessary control of fluid flow and pressure. With a wide range of options available, including the DCV20, DCV40, DCV45, P40, P80, P81, and P120, as well as the HSSD, HSSD5, HSSD11, HSV, HSGK, RD, ZT, DF, DFS, and DL series, there is a valve suitable for every hydraulic system.
The DCV20, DCV40, and DCV45 series are compact and durable, making them ideal for use in mobile equipment and other applications with limited space. The P40, P80, P81, and P120 series offer superior performance and reliability for larger hydraulic systems. The HSSD, HSSD5, HSSD11, HSV, HSGK, RD, ZT, DF, DFS, and DL series offer a range of features such as manual overrides, adjustable relief valves, and multiple spool options to meet specific system requirements.
No matter which Monoblock directional control valve series you choose, you can expect exceptional quality and performance from a trusted brand. With so many options to choose from, you’re sure to find the perfect valve for your needs. Contact us today to learn more about how we can help you with your hydraulic system needs.
DCV Directional Control Valve
In stock
| Flow |
20~200 L/min |
|---|---|
| Number of spools |
1~12 spools |
| Inlet section type |
Side inlet, withrelief vaive, lnlet port on top of inletsection,Outiet onoutlet section (only forDCV60-100see table7F5-8), Top inlet,withrelief valve, Inlet and outletpart ontop of inlet section(only for DCV60-100match F7 in table 7) |
| Relief valve set pressure |
100~250 bar |
| Control type |
manual, joystick,cable, solenoid, pneumatic, electro-hydraulic, electro-pneumatic |
| Spool type |
3 positions,double acting, 3 positions.double acting.A&B open, 3 positions,double actingA open.B blocked, 3 positions, double actingA blocked.B open, 3 positions,singleacting in A.A open, 4 positions,doubleacting with 4th floatingposition |
| Port size |
G1/4, G3/8, G1/2, G3/4, G1, M16X1.5, M18X1.5, M20X1.5, M22X1.5, M27X2, 5/8-12UNF, 3/4-16UNF, 7/8-14UNF, 1-12UNF, 11/8-12UNF, NPT3/8, NPT1/2, NPT3/4, NPT1 |
DCV20 Manual Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
20 L/min |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
350 bar (35 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-6 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
DCV40 Electro-hydraulic Directional Control Valve
In stock
| Control Method |
electro-hydraulic |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
40 L/min |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
350 bar (35 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-6 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
DCV40 Manual Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
40 L/min |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
350 bar (35 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-6 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
DCV40 Pneumatic Directional Control Valve
In stock
| Control Method |
pneumatic |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
40 L/min |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
350 bar (35 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-6 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
DCV40Z Under Carriage Valve
In stock
| Control Method |
cable, electro-hydraulic, electro-pneumatic, joystick, manual, pneumatic, solenoid |
|---|---|
| Valve Structure |
Monoblock Valve |
| Nominal Flow |
40 L/min (10.5 gpm) |
| Max Pressure |
350 bar (35 MPa) |
| Operating Range |
15-75 mm²/s (15-75 CST) |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Sections |
1-5 sections |
| Number of Spools |
1 spool, 2 spool, 3 spool, 4 spool, 5 spool |
DF5 Series Rupture Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
60 L/min (15.8 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
315 bar (31.5 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
DF50 Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
50 L/min (13.2 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
200 bar (20 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-3 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
DF80 Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
80 L/min (21 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
200 bar (20 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-10 Sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
DM45 Directional Control Valve
In stock
| Valve Structure |
Monoblock Valve |
|---|---|
| Control Method |
cable, electro-hydraulic, electro-pneumatic, joystick, manual, pneumatic, solenoid |
| Nominal Flow |
45 L/min (12 gpm) |
| Operating Pressure |
315 bar (31.5 MPa) |
| Viscosity Range |
12 CST-400 CST |
| Operating Range |
15-75 mm²/s (15-75 CST) |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Sections |
1-7 sections |
HSSD Directional Control Valve
In stock
| Flow |
45~380 L/min |
|---|---|
| Operating Pressure |
250-350 bar (25-35 MPa) |
| Operating Range |
15-75 mm²/s (15-75 CST) |
| Viscosity Range |
12-400 mm²/s |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
monoblock, sectional |
| Valve Sections |
1-12 Sections |
| Presure Medium |
Mineral oil based hydraulic oil |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Spool Stroke |
±6mm |
| Valve Surface |
Phosphating treating |
| Rustproof Level |
Neutral salt spray test, 48hours |
HSSD11 Manual Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
75 L/min (19.6 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
315 bar (31.5 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
HSSD14 Manual Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
120 L/min (31.5 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
250 bar (25 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
Only one sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
HSSD18 Manual Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
160 L/min (42 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
250 bar (25 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-4 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
HSSD4 Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
45 L/min (12 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
250 bar (25 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
Only one sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
HSSD4R Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
45 L/min (12 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
250 bar (25 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
Only one sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
Our Products and Services
Here's what we can do
Our main products include Directional Control Valves, Gear Pumps, Steering Equipment, and Power Units, with over 500 models that are widely used in various industries such as construction, sanitation, drilling, and mining. In addition to our standard product offerings, we also support OEM/ODM services, allowing us to customize hydraulic products according to our customers' specific needs and requirements. Our professional R&D team and advanced production technology ensure the quality and timely delivery of our products, while our comprehensive pre-sales and after-sales services help our customers improve their product competitiveness.
