Showing 19–36 of 121 results
BXHS Directional Valves: 11.8 GPM 2-Spool Monoblock DM45 – Manufacturing, OEM & Distribution
In stock
Weight | 10.50 kg |
---|---|
Dimensions | 25 × 35 × 18 cm |
Control Method |
cable |
Section |
2 Section |
Structure Type |
Monoblock valve |
Rated Flow |
45 L/min (11.8 US gpm) |
Max Pressure |
315 bar (31.5 MPa) |
Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
Spool |
2 Spool |
Product Model |
DM45 Cable |
BXHS Electro-Hydraulic Directional Valves (21.2 GPM, 3 Spool) – Manufacturer & Distributor
In stock
Weight | 18.00 kg |
---|---|
Dimensions | 35 × 38 × 21 cm |
Control Method |
electro-hydraulic |
Section |
3 Section |
Structure Type |
Monoblock valve |
Rated Flow |
80 L/min (21.2 US gpm) |
Max Pressure |
315 bar (31.5 MPa) |
Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
Spool |
3 Spool |
Product Model |
P80 Electro-hydraulic |
BXHS Hydraulic Directional Valves: 21.2 GPM 5-Spool Solenoid P80 Monoblock – Global Distributor Network Sought
In stock
Weight | 19.50 kg |
---|---|
Dimensions | 33 × 44 × 11 cm |
Control Method |
solenoid |
Section |
5 Section |
Structure Type |
Monoblock valve |
Rated Flow |
80 L/min (21.2 US gpm) |
Max Pressure |
315 bar (31.5 MPa) |
Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
Spool |
5 Spool |
Product Model |
P80 Solenoid |
BXHS Hydraulic Directional Valves: 31.7 GPM 2-Spool Manual P120 – Global Supply & Distribution
In stock
Weight | 19.00 kg |
---|---|
Dimensions | 30 × 39 × 17 cm |
Control Method |
manual |
Section |
2 Section |
Structure Type |
Monoblock valve |
Rated Flow |
120 L/min (31.7 US gpm) |
Max Pressure |
250 bar (25 MPa) |
Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
Spool |
2 Spool |
Product Model |
P120 Manual |
BXHS Hydraulic Monoblock Valve (10.5 GPM) – SD5 Solenoid, Custom Manufacturing Available
In stock
Weight | 5.40 kg |
---|---|
Dimensions | 30 × 13 × 13 cm |
Control Method |
solenoid |
Section |
1 Section |
Structure Type |
Monoblock valve |
Rated Flow |
40 L/min (10.5 US gpm) |
Max Pressure |
315 bar (31.5 MPa) |
Spool |
1 Spool |
Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
Product model |
SD5 Solenoid |
BXHS Hydraulic Monoblock Valve (21.2 GPM, 3-Spool Solenoid P80) – Global Manufacturer & Distributor
In stock
Weight | 13.00 kg |
---|---|
Dimensions | 33 × 28 × 11 cm |
Control Method |
solenoid |
Section |
3 Section |
Structure Type |
Monoblock valve |
Rated Flow |
80 L/min (21.2 US gpm) |
Max Pressure |
315 bar (31.5 MPa) |
Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
Spool |
3 Spool |
Product Model |
P80 Solenoid |
BXHS Hydraulic Monoblock Valves: 21.2 GPM 3-Spool Cable P80 – Global Distributor & Wholesale Opportunities
In stock
Weight | 9.60 kg |
---|---|
Dimensions | 22 × 35 × 10 cm |
Control Method |
cable |
Section |
3 Section |
Structure Type |
Monoblock valve |
Rated Flow |
80 L/min (21.2 US gpm) |
Max Pressure |
315 bar (31.5 MPa) |
Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
Spool |
3 Spool |
Product Model |
P80 Cable |
BXHS Hydraulic Valves: 10.5 GPM 4-Spool Monoblock Directional Valve (P40) – Manufacturing, Wholesale & Distribution
In stock
Weight | 12.30 kg |
---|---|
Dimensions | 33 × 35 × 17 cm |
Control Method |
Hydraulic and Manual |
Section |
4 Section |
Structure Type |
Monoblock valve |
Rated Flow |
40 L/min (10.5 US gpm) |
Max Pressure |
250 bar (25 MPa) |
Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
Spool |
4 Spool |
Product Model |
P40 Hydraulic and Manual |
BXHS Hydraulic Valves: Wholesale Monoblock Directional Valve (10.5 GPM, 7 Spool, Manual SD5) – Global Distribution
In stock
Weight | 15.30 kg |
---|---|
Dimensions | 23 × 36 × 13 cm |
Control Method |
manual |
Section |
7 Section |
Structure Type |
Monoblock valve |
Rated Flow |
40 L/min (10.5 US gpm) |
Max Pressure |
315 bar (31.5 MPa) |
Spool |
7 Spool |
Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
Product model |
SD5 Manual |
BXHS Pneumatic Directional Valve (SD18): 42.2 GPM, 1 Spool – Global Supplier & Distributor Network
In stock
Weight | 14.90 kg |
---|---|
Dimensions | 27 × 44 × 16 cm |
Control Method |
pneumatic |
Section |
1 Section |
Structure Type |
Monoblock valve |
Rated Flow |
160 L/min (42.2 US gpm) |
Max Pressure |
315 bar (31.5 MPa) |
Spool |
1 Spool |
Operating Viscosity Range |
12 – 400 mm²/s (12 cSt to 400 cSt) |
Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
Product model |
SD18 Pneumatic |
DCV Directional Control Valve
In stock
Flow |
20~200 L/min |
---|---|
Number of spools |
1~12 spools |
Inlet section type |
Side inlet, withrelief vaive, lnlet port on top of inletsection,Outiet onoutlet section (only forDCV60-100see table7F5-8), Top inlet,withrelief valve, Inlet and outletpart ontop of inlet section(only for DCV60-100match F7 in table 7) |
Relief valve set pressure |
100~250 bar |
Control type |
manual, joystick,cable, solenoid, pneumatic, electro-hydraulic, electro-pneumatic |
Spool type |
3 positions,double acting, 3 positions.double acting.A&B open, 3 positions,double actingA open.B blocked, 3 positions, double actingA blocked.B open, 3 positions,singleacting in A.A open, 4 positions,doubleacting with 4th floatingposition |
Port size |
G1/4, G3/8, G1/2, G3/4, G1, M16X1.5, M18X1.5, M20X1.5, M22X1.5, M27X2, 5/8-12UNF, 3/4-16UNF, 7/8-14UNF, 1-12UNF, 11/8-12UNF, NPT3/8, NPT1/2, NPT3/4, NPT1 |
DCV20 Manual Directional Control Valve
In stock
Control Method |
manual |
---|---|
Presure Medium |
Mineral oil based hydraulic oil |
Nominal Flow |
20 L/min |
Viscosity Range |
12 CST-400 CST |
Operating Pressure |
350 bar (35 MPa) |
Internal Leakage |
15 cc/min at 160 bar, 50℃ |
Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
Valve Structure |
Monoblock Valve |
Valve Surface |
Phosphating treating |
Valve Sections |
1-6 sections |
Rustproof Level |
Neutral salt spray test, 48hours |
DCV40 Electro-hydraulic Directional Control Valve
In stock
Control Method |
electro-hydraulic |
---|---|
Presure Medium |
Mineral oil based hydraulic oil |
Nominal Flow |
40 L/min |
Viscosity Range |
12 CST-400 CST |
Operating Pressure |
350 bar (35 MPa) |
Internal Leakage |
15 cc/min at 160 bar, 50℃ |
Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
Valve Structure |
Monoblock Valve |
Valve Surface |
Phosphating treating |
Valve Sections |
1-6 sections |
Rustproof Level |
Neutral salt spray test, 48hours |
DCV40 Manual Directional Control Valve
In stock
Control Method |
manual |
---|---|
Presure Medium |
Mineral oil based hydraulic oil |
Nominal Flow |
40 L/min |
Viscosity Range |
12 CST-400 CST |
Operating Pressure |
350 bar (35 MPa) |
Internal Leakage |
15 cc/min at 160 bar, 50℃ |
Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
Valve Structure |
Monoblock Valve |
Valve Surface |
Phosphating treating |
Valve Sections |
1-6 sections |
Rustproof Level |
Neutral salt spray test, 48hours |
DCV40 Pneumatic Directional Control Valve
In stock
Control Method |
pneumatic |
---|---|
Presure Medium |
Mineral oil based hydraulic oil |
Nominal Flow |
40 L/min |
Viscosity Range |
12 CST-400 CST |
Operating Pressure |
350 bar (35 MPa) |
Internal Leakage |
15 cc/min at 160 bar, 50℃ |
Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
Valve Structure |
Monoblock Valve |
Valve Surface |
Phosphating treating |
Valve Sections |
1-6 sections |
Rustproof Level |
Neutral salt spray test, 48hours |
DCV40Z Under Carriage Valve
In stock
Control Method |
cable, electro-hydraulic, electro-pneumatic, joystick, manual, pneumatic, solenoid |
---|---|
Valve Structure |
Monoblock Valve |
Nominal Flow |
40 L/min (10.5 gpm) |
Max Pressure |
350 bar (35 MPa) |
Operating Range |
15-75 mm²/s (15-75 CST) |
Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
Valve Sections |
1-5 sections |
Number of Spools |
1 spool, 2 spool, 3 spool, 4 spool, 5 spool |
DF5 Series Rupture Valve
In stock
Control Method |
manual |
---|---|
Presure Medium |
Mineral oil based hydraulic oil |
Nominal Flow |
60 L/min (15.8 gpm) |
Viscosity Range |
12 CST-400 CST |
Operating Pressure |
315 bar (31.5 MPa) |
Internal Leakage |
15 cc/min at 160 bar, 50℃ |
Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
Valve Structure |
Monoblock Valve |
Valve Surface |
Phosphating treating |
Valve Sections |
1-7 sections |
Rustproof Level |
Neutral salt spray test, 48hours |
DF50 Directional Control Valve
In stock
Control Method |
manual |
---|---|
Presure Medium |
Mineral oil based hydraulic oil |
Nominal Flow |
50 L/min (13.2 gpm) |
Viscosity Range |
12 CST-400 CST |
Operating Pressure |
200 bar (20 MPa) |
Internal Leakage |
15 cc/min at 160 bar, 50℃ |
Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
Valve Structure |
Monoblock Valve |
Valve Surface |
Phosphating treating |
Valve Sections |
1-3 sections |
Rustproof Level |
Neutral salt spray test, 48hours |
