All productsShowing 1–18 of 109 results
26.5 GPM 4-Spool Manual Hydraulic Distributor (CDBF20) – Distributor, Wholesaler & Agent Inquiries Welcome
In stock
| Weight | 36.00 kg |
|---|---|
| Dimensions | 38 × 40 × 25 cm |
| Control Method |
manual |
| Section |
4 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
100 L/min (26.4 gpm) |
| Max Pressure |
315 bar (31.5 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| spool |
4 Spool |
| Product model |
CDBF20 Manual |
BKQF34-D 10.5 GPM Pneumatic Control Valve: Manufacturer, Supplier & Global Distributor
In stock
| Weight | 0.38 kg |
|---|---|
| Dimensions | 23 × 10 × 8 cm |
| Control Method |
pneumatic |
| Section |
1 Section |
| Structure Type |
Monoblock valve |
| Rated Flow |
40 L/min (10.5 US gpm) |
| Max Pressure |
1 MPa (145 psi) |
| Operating Viscosity Range |
12 – 400 mm²/s (12 cSt to 400 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| spool |
1 Spool |
| Product model |
BKQF34-D Pneumatic |
BXHS Electro-hydraulic Directional Control Valve (26.5 GPM, 2 Spool) – DCV100 Wholesale & Distribution Available
In stock
| Weight | 24.00 kg |
|---|---|
| Dimensions | 41 × 30 × 16 cm |
| Control Method |
electro-hydraulic |
| Section |
2 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
100 L/min (26.4 gpm) |
| Max Pressure |
350 bar (35 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
2 Spool |
| Product Model |
DCV100 Electro-hydraulic |
BXHS Hydraulic Directional Valves: 21.2 GPM 5-Spool Solenoid P80 Monoblock – Global Distributor Network Sought
In stock
| Weight | 19.50 kg |
|---|---|
| Dimensions | 33 × 44 × 11 cm |
| Control Method |
solenoid |
| Section |
5 Section |
| Structure Type |
Monoblock valve |
| Rated Flow |
80 L/min (21.2 US gpm) |
| Max Pressure |
315 bar (31.5 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
5 Spool |
| Product Model |
P80 Solenoid |
BXHS Hydraulic Monoblock Valve (21.2 GPM, 3-Spool Solenoid P80) – Global Manufacturer & Distributor
In stock
| Weight | 13.00 kg |
|---|---|
| Dimensions | 33 × 28 × 11 cm |
| Control Method |
solenoid |
| Section |
3 Section |
| Structure Type |
Monoblock valve |
| Rated Flow |
80 L/min (21.2 US gpm) |
| Max Pressure |
315 bar (31.5 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
3 Spool |
| Product Model |
P80 Solenoid |
BXHS Hydraulic Monoblock Valves: 21.2 GPM 3-Spool Cable P80 – Global Distributor & Wholesale Opportunities
In stock
| Weight | 9.60 kg |
|---|---|
| Dimensions | 22 × 35 × 10 cm |
| Control Method |
cable |
| Section |
3 Section |
| Structure Type |
Monoblock valve |
| Rated Flow |
80 L/min (21.2 US gpm) |
| Max Pressure |
315 bar (31.5 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
3 Spool |
| Product Model |
P80 Cable |
BXHS Hydraulic Valves: 10.5 GPM 4-Spool Monoblock Directional Valve (P40) – Manufacturing, Wholesale & Distribution
In stock
| Weight | 12.30 kg |
|---|---|
| Dimensions | 33 × 35 × 17 cm |
| Control Method |
Hydraulic and Manual |
| Section |
4 Section |
| Structure Type |
Monoblock valve |
| Rated Flow |
40 L/min (10.5 US gpm) |
| Max Pressure |
250 bar (25 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
4 Spool |
| Product Model |
P40 Hydraulic and Manual |
CDB15 Series Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Rated Flow |
63 L/min (16.6 gpm) |
| Rated Pressure |
200 bar (20 MPa) |
| Nom. Diameter |
15 mm |
| Dividing Flow |
8-12 L/min |
| Dividing Flow Valve Pressure |
90 bar (9 MPa) |
| Number of Spools |
1 spool, 2 spool, 3 spool, 4 spool, 5 spool, 6 spool, 7 spool, 8 spool, 9 spool, 10 spool |
| Valve Sections |
1-10 Sections |
DCV Directional Control Valve
In stock
| Flow |
20~200 L/min |
|---|---|
| Number of spools |
1~12 spools |
| Inlet section type |
Side inlet, withrelief vaive, lnlet port on top of inletsection,Outiet onoutlet section (only forDCV60-100see table7F5-8), Top inlet,withrelief valve, Inlet and outletpart ontop of inlet section(only for DCV60-100match F7 in table 7) |
| Relief valve set pressure |
100~250 bar |
| Control type |
manual, joystick,cable, solenoid, pneumatic, electro-hydraulic, electro-pneumatic |
| Spool type |
3 positions,double acting, 3 positions.double acting.A&B open, 3 positions,double actingA open.B blocked, 3 positions, double actingA blocked.B open, 3 positions,singleacting in A.A open, 4 positions,doubleacting with 4th floatingposition |
| Port size |
G1/4, G3/8, G1/2, G3/4, G1, M16X1.5, M18X1.5, M20X1.5, M22X1.5, M27X2, 5/8-12UNF, 3/4-16UNF, 7/8-14UNF, 1-12UNF, 11/8-12UNF, NPT3/8, NPT1/2, NPT3/4, NPT1 |
DCV100 Electro-hydraulic Directional Control Valve
In stock
| Control Method |
electro-hydraulic |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
100 L/min |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
350 bar (35 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Sectional Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-12 Sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
DCV100 Electro-pneumatic Directional Control Valve
In stock
| Control Method |
electro-pneumatic |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
100 L/min |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
350 bar (35 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Sectional Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-12 Sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
DCV100 Manual Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
100 L/min |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
350 bar (35 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Sectional Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-12 Sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
DCV100 Pneumatic Directional Control Valve
In stock
| Control Method |
pneumatic |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
100 L/min |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
350 bar (35 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Sectional Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-12 Sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
DCV140 Electro-hydraulic Directional Control Valve
In stock
| Control Method |
electro-hydraulic |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
140 L/min |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
350 bar (35 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Sectional Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-12 Sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
DCV140 Electro-pneumatic Directional Control Valve
In stock
| Control Method |
electro-pneumatic |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
140 L/min |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
350 bar (35 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Sectional Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-12 Sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
Our Products and Services
Here's what we can do
Our main products include Directional Control Valves, Gear Pumps, Steering Equipment, and Power Units, with over 500 models that are widely used in various industries such as construction, sanitation, drilling, and mining. In addition to our standard product offerings, we also support OEM/ODM services, allowing us to customize hydraulic products according to our customers' specific needs and requirements. Our professional R&D team and advanced production technology ensure the quality and timely delivery of our products, while our comprehensive pre-sales and after-sales services help our customers improve their product competitiveness.
