All productsShowing all 14 results
CDB15 Series Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Rated Flow |
63 L/min (16.6 gpm) |
| Rated Pressure |
200 bar (20 MPa) |
| Nom. Diameter |
15 mm |
| Dividing Flow |
8-12 L/min |
| Dividing Flow Valve Pressure |
90 bar (9 MPa) |
| Number of Spools |
1 spool, 2 spool, 3 spool, 4 spool, 5 spool, 6 spool, 7 spool, 8 spool, 9 spool, 10 spool |
| Valve Sections |
1-10 Sections |
DCV Directional Control Valve
In stock
| Flow |
20~200 L/min |
|---|---|
| Number of spools |
1~12 spools |
| Inlet section type |
Side inlet, withrelief vaive, lnlet port on top of inletsection,Outiet onoutlet section (only forDCV60-100see table7F5-8), Top inlet,withrelief valve, Inlet and outletpart ontop of inlet section(only for DCV60-100match F7 in table 7) |
| Relief valve set pressure |
100~250 bar |
| Control type |
manual, joystick,cable, solenoid, pneumatic, electro-hydraulic, electro-pneumatic |
| Spool type |
3 positions,double acting, 3 positions.double acting.A&B open, 3 positions,double actingA open.B blocked, 3 positions, double actingA blocked.B open, 3 positions,singleacting in A.A open, 4 positions,doubleacting with 4th floatingposition |
| Port size |
G1/4, G3/8, G1/2, G3/4, G1, M16X1.5, M18X1.5, M20X1.5, M22X1.5, M27X2, 5/8-12UNF, 3/4-16UNF, 7/8-14UNF, 1-12UNF, 11/8-12UNF, NPT3/8, NPT1/2, NPT3/4, NPT1 |
DF50 Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
50 L/min (13.2 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
200 bar (20 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-3 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
DF80 Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
80 L/min (21 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
200 bar (20 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-10 Sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
HSSD Directional Control Valve
In stock
| Flow |
45~380 L/min |
|---|---|
| Operating Pressure |
250-350 bar (25-35 MPa) |
| Operating Range |
15-75 mm²/s (15-75 CST) |
| Viscosity Range |
12-400 mm²/s |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
monoblock, sectional |
| Valve Sections |
1-12 Sections |
| Presure Medium |
Mineral oil based hydraulic oil |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Spool Stroke |
±6mm |
| Valve Surface |
Phosphating treating |
| Rustproof Level |
Neutral salt spray test, 48hours |
LS755 Log Splitter Valve
In stock
| Rated Flow |
63 L/min (16.6 gpm) |
|---|---|
| Max Pressure |
250 bar (25 MPa) |
| Valve Structure |
Monoblock |
| Control Method |
manual |
| Operating Range |
15-75 mm²/s (15-75 CST) |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Kick out set pressure |
70-140 bar (1015-2030 psi) |
| Number of Spools |
1 spool |
| Valve Sections |
Only one sections |
MPC70 Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
70 L/min (12 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
250 bar (25 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
P40/P80/P120 Directional Control Valve
In stock
| Flow |
40~120 L/min |
|---|---|
| Number of spools |
1~7 sections |
| Relief valve set pressure |
100~250 bar |
| Control type |
manual, cable, solenoid, pneumatic, electro-hydraulic |
| Spool type |
3 positions,double acting, 3 positions.double acting.A&B open, 3 positions,double actingA open.B blocked, 3 positions, double actingA blocked.B open, 3 positions,singleacting in A.A open, 4 positions,doubleacting with 4th floatingposition |
| Spool returning type |
3 postions,springreturn, 3 postions,springreturn, detent in a and b, 3 postions,spring return,detent in a, 3 postions,spring return,detent in b, 4 positions.spring return,detent in 4 th position, 4 positions.detent in all 4 positions, 3 positions.detent in 0,a & b, 2 positions(0.b),springreturn, 2 positions(0,a).springreturn |
| Port size |
G1/4, G3/8, G1/2, G3/4, G1, M16X1.5, M18X1.5, M20X1.5, M22X1.5, M27X2, 5/8-12UNF, 3/4-16UNF, 7/8-14UNF, 1-12UNF, 11/8-12UNF, NPT3/8, NPT1/2, NPT3/4, NPT1 |
YDF15 Series Valve for Agricultural Machine
In stock
| Presure Medium |
Mineral oil based hydraulic oil |
|---|---|
| Nominal Flow |
65 L/min (17 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
200 bar (20 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
Our Products and Services
Here's what we can do
Our main products include Directional Control Valves, Gear Pumps, Steering Equipment, and Power Units, with over 500 models that are widely used in various industries such as construction, sanitation, drilling, and mining. In addition to our standard product offerings, we also support OEM/ODM services, allowing us to customize hydraulic products according to our customers' specific needs and requirements. Our professional R&D team and advanced production technology ensure the quality and timely delivery of our products, while our comprehensive pre-sales and after-sales services help our customers improve their product competitiveness.
